Professional diesel Generator Diesel Generator Set Powered by Doosan Super Silent Open 600kW 750KVA Power Plant

Professional diesel Generator Diesel Generator Set Powered by Doosan Super Silent Open 600kW 750KVA Power Plant
Features Gallery Product Description Request A Quote
Features
Specifications
Canopy: Customized
Warranty: 12 Months/1000 Hours
Type: Silent(super Silent)or Open, Silent, Etc, In-line/6-Cylinder/4-Stroke/4-Valve/19L, Soundproof Canopy(Silent)
Control Panel: LCD Digital Display, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen
Output Type: AC Single/Three Phase
Controller: Deepsea/Smartgen/etc
Application: Indursty Bank Etc
Rated Voltage: 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V
Alternator: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford Or Newtec, Engga
Product Name: Diesel Genertor, Generator 600kW , Powered By Doosan Diesel Generator, Standby Use Power Diesel Generator 750KVA
Color: Customers' Requirement
Frequency: 50/60HZ
Rated Power: 600kW
Engine: Original Doosan
Cooling Method: Water-cooling System
Highlight:

600kW silent diesel generator

,

750KVA Doosan diesel generator

,

super silent diesel power plant
Basic Infomation
Place of Origin: China
Brand Name: Doosan
Certification: CE
Model Number: DP222LC
Payment & Shipping Terms
Packaging Details: Bubble wrap
Delivery Time: 30 days
Supply Ability: 3000 Sets/Month
Product Description
600kW 750KVA BOBIG Doosan Diesel Generator (Model: DP222LC)
Our 600kW 750KVA BOBIG Doosan diesel generator (Model: DP222LC) is engineered to deliver reliable power for diverse industrial, commercial, and residential applications. Backed by the trusted Doosan brand, it ensures high-quality performance and long-term durability.
Key Features
Power Performance
Rated at 600kW (750KVA), this generator provides stable prime power output suitable for continuous operation under heavy loads. It operates at a standard frequency of 50Hz, compatible with most electrical equipment.
Engine Excellence
Powered by the DP222LC Doosan engine, this unit combines advanced technology with high-quality manufacturing. The engine delivers high torque, fuel efficiency, and low emissions while running at 1500 RPM for smooth, consistent power.
Technical Specifications
General InformationPrime PowerStandby Power
Rated Power (kVA)750825
Power Rating (kW)600660
Frequency (Hz)50
Engine ModelDP222LC
Engine Speed (RPM)1500
Phase3
PF0.8
Control SystemDigital
Rated Voltage (V)400/230 (customizable)
Fuel Tank Capacity Operating Time≥ 8h @ 75% load
Dimensions and Weight
ModelBDO825 (Open)BDO825S (Silent)
Length (mm)45005600
Width (mm)18002200
Height (mm)27452550
Tank Capacity (L)13801380
Engine Details
Engine Model & ManufacturerDP222LC (DOOSAN)
Engine TypeDiesel, water cooled, Turbo charged & intercooled
Bore x Stroke128 × 142mm
Displacement21.9 liters
Cylinders and ArrangementCast iron, 12 cylinder, Vee-Type
Battery Charging Alternator27.5V x 45A alternator
Starting Voltage24V
Fuel SystemMechanical Injection Pump
Fuel FilterFull flow, cartridge type with water drain valve
Lube Oil Filter TypeFull flow, cartridge type
Lube Oil CapacityMax. 40 liters, Min. 27 liters
Flywheel DimensionsClutch No. 14 M
Dry Weight1420kg (engine only)
Dimension (LxWxH)1738 × 1389 × 1258 mm
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-354FS
Alternator Rated Power600kw/750kva
Rated Voltage (V)230v/400v
Rated Frequency50hz
Connecting Type3 Phase and 4 W
Number of Bearing1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation ClassH class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%~+20%
Environmental Adaptability
Operates effectively in ambient temperatures from +5°C to +40°C and at altitudes up to 1000m. Custom solutions available for different environmental conditions.
Certifications and Standards
Complies with ISO 8528-5:2018, GB/T2820.5-2009, and CE standards, ensuring quality, safety, and reliability.
Product Certification 1 Product Certification 2
Customization and Options
We support customization and OEM services with design drawings. All units include standard DSE 6120 controller (engine, generator, and controller options available).
Generator Controller Interface
Applications
  • Industrial Use: Backup power for factories to ensure continuous production during outages
  • Commercial Buildings: Power for office buildings, shopping malls, and hotels to maintain essential services
  • Residential Areas: Reliable power for communities with unstable power grids
Warranty and Service
BOBIG products include a one-year or 1000-hour warranty (whichever comes first). Free replacement of easy-damageable spare parts during warranty period. Professional after-sales support available 24/7.
Packaging and Shipping
Plywood case packaging. Delivery within 10-15 working days after receiving customer deposit.
Why Choose BOBIG
  • Brand Reputation: Partnership with Doosan, a trusted name in diesel generators
  • Quality Assurance: Manufactured to international standards with rigorous inspections
  • Customization Options: Tailored solutions for specific customer requirements
