Diesel Generator Perkings Wechai Yuchai Deutz Sdec Super Silent Open 20kw 30kw 50kw 100kw 200kw 400kw 500kw 800kw 1000kw

1
MOQ
USD+2648.18
Price
Diesel Generator Perkings Wechai Yuchai Deutz Sdec Super Silent Open 20kw 30kw 50kw 100kw 200kw 400kw 500kw 800kw 1000kw
Features Gallery Product Description Request A Quote
Features
Specifications
Power Rating: 52kw
Rated Power: 65kva
Control System: Digital
Tank Capacity: 184L
Phase: 3
Frequency: 50/60HZ
Rpm: 1500/1800
Type: Silent/Open
Alternator: China Stamford,original Stamford, Leroy Somer
Package: Plywood, Plastic Film Packing
Highlight:

Silent Diesel Generator 20kw

,

Perkins Diesel Generator 100kw

,

Super Silent Diesel Generator 500kw
Basic Infomation
Place of Origin: China
Brand Name: Baudouin
Certification: CE
Model Number: 4M10G110/5
Payment & Shipping Terms
Packaging Details: 190cm*75cm*138cm
Delivery Time: 20-30 work days
Payment Terms: L/C, T/T
Product Description
Industrial Diesel Generator Solutions
High-performance 52KW diesel generator set designed for industrial applications requiring continuous operation with minimal noise disruption.
Key Features
  • Heavy-duty steel canopy with high-density sound-absorbing materials for quiet operation
  • Integrated bottom fuel tank with automatic start controller for instant power backup
  • 8-hour continuous runtime at 75% load capacity
  • Premium engine options: Baudouin, Doosan, WEICHAI, YUCHAI, SDEC, or YANGDONG
  • Global warranty and comprehensive after-sales support
Our 4M10G110/5 model delivers reliable power for industrial and commercial applications with customizable power options to meet specific requirements.
Industrial diesel generator set in operational environment
Technical Specifications
Power Ratings
General information Prime power Standby power
Rated Power (kVA) 100 110
Power Rating (kW) 80 88
Frequency (Hz) 50
Engine Model 4M10G110/5
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated voltage (V) 400/230 (According to customer requirements)
Fuel tank capacity operating time ≥ 8h @ 75% load
PRP - Prime Power Rating
Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97. A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP - Emergency Standby Power
The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Generator dimensions diagram and technical specifications
Dimensions and Weight
Dimension and Weight Open type BBDA110 Silent type BBDA110S
Length (L) mm 1900 3150
Width (W) mm 750 1040
Height (H) mm 1380 1610
Tank capacity (L) 184 184
Engine Specifications
Specification Details
Engine model & manufacturer 4M10G110/5 (BAUDOUIN)
Engine model 4M10G110/5
N° of Cylinders / Valves 4/8
Cylinders arrangement In line
Bore x Stroke (mm) 105 × 118
Displacement (L) 4.087
Thermodynamic Cycle Diesel 4 stroke
Firing Order 1-3-4-2
Mean Piston Speed (m/s) 5.9
BMEP @ ESP (Bar) 20.80
Cooling System Liquid (water + 50% antifreeze)
Injection System Direct
Fuel System Mechanical Pump
Aspiration Turbocharged and Aftercooled
Compression ratio 17.5 : 1
Flywheel housing SAE 3
Flywheel 11.5"
Rotation Viewed from Flywheel Counter Clockwise
Allowed static bending moment of the flywheel housing 7000
N° of teeth on flywheel ring gear 128
Inertia of flywheel (kg•m²) 0.391
Inertia of crankshaft (kg•m²) 0.111
Emission standard N/A
Overall Dimensions with radiator (Length x Width x Height) (mm) 1330×741×995
Engine dry weight without radiator and without radiator pipes (kg) 400
Engine dry weight with radiator and radiator pipes (kg) 495
Engine wet weight with radiator (includes oil, coolant) (kg) 530
Alternator Specifications
Specification Details
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-224G
Alternator Rated Power 80kw/100kva
Rated voltage (V) 230v/400v
Rated frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%～+20%
Manufacturer Profile
Established in 2004, Fujian Bobig Electric Machinery Co., Ltd. specializes in technological research, production, and sales of electrical machinery. Operating from a 10,000 square meter facility with 160 employees including 20 technicians.
Product Range
Comprehensive product line including air-cooled gasoline generators, air-cooled diesel generators, air-cooled welding & generating sets, and water-cooled diesel generator sets. Known for reliable quality in small air-cooled brushless generators and welding sets.
Quality Commitment
Adhering to "Quality, Creation, Service and Development" principles with continuous technology updates and quality improvements. Advanced testing equipment includes CAD systems, automated assembly equipment, and digital testing systems. ISO9000 Quality System Certified.
Bobig Electric Machinery production line and assembly process Bobig Electric Machinery quality control inspection Bobig Electric Machinery manufacturing facility Bobig Electric Machinery facility overview Generator packing condition and preparation Bobig Electric Machinery manufacturing process
International Trade Experience
The 139th Canton Fair April 2026
Bobig Electric Machinery trade show participation at Canton Fair Bobig Electric Machinery international trade exhibition booth
The 137th Canton Fair April 2025
Canton Fair exhibition 2025 showcasing generators International trade showcase 2025 with product display
After Sales Services
Customized manufacturing solutions
Comprehensive quality control
International logistics management
Documentation and certification support
Trade support services
After-sales technical assistance
Customer training programs
Market support initiatives
Technical collaboration opportunities
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are a professional manufacturer with our own factory located in Fujian, China. We welcome facility visits to observe our quality control processes firsthand.
What is the minimum order quantity (MOQ)?
Standard MOQ is 1 set. We offer flexible terms for volume orders and provide competitive pricing for larger projects.
What is the delivery time after order confirmation?
Production time varies by quantity and inventory status. Standard models typically require 20-30 days. We provide precise timelines upon order confirmation.
What payment terms do you offer?
We commonly accept T/T with 30% deposit and 70% balance before shipment. For established relationships, we can discuss alternative terms including L/C.
Do you perform factory inspection before shipment?
Yes, every unit undergoes thorough testing and inspection in our factory before shipment to ensure quality and performance standards.
