Name: Customized Factory Price Open/Silent Type SDEC Diesel Generator 200KW/250KVA Power Supply Water Cooling
Brand: FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
SKU: 6DTAA8.9-G23
Price: 3,449.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Speed: 1500RPM

Frequency: 50/60HZ

Rated Power: 5KW To 2000KW

Output Type: AC Three Phase

Type: Open Or Silent(super Silent)

Color: At Your Requirement,Customized

Highlight:

200KW SDEC diesel generator water cooling

silent type SDEC diesel generator 250KVA

factory price customized diesel generator

Basic Infomation

Place of Origin: CHINA

Brand Name: SDEC

Model Number: 6DTAA8.9-G23

Payment & Shipping Terms

Packaging Details: plywood

Delivery Time: 20work days

Payment Terms: L/C, T/T

Supply Ability: 50sets per month

Gallery

Customized Factory Price Open/Silent Type SDEC Diesel Generator 200KW/250KVA Power Supply Water Cooling

Product Description

Customized Factory Price Open/Silent Type SDEC Diesel Generator 200KW/250KVA Power Supply Water Cooling

High Quality Open/Silent Type SDEC Diesel Generator providing reliable 200KW/250KVA backup power supply with water cooling system. Available in both open and silent configurations to meet diverse operational requirements.

Key Features

Equipped with famous brushless alternator brands: Leroy Somer, Marathon, BOBIG, Mecc Alte
50°C radiator with fan for optimal engine cooling during extended operation
Advanced control systems including generator set control, ATS system, remote control, and parallel operation
High-quality steel canopy construction (2MM to 6MM thickness)
High-density sound-absorbing material for effective sound insulation and fireproofing
12V/24V DC battery with charger and connecting wires
10-12 hours fuel tank with fuel indicator for continuous operation
High protection class control box (IP55) with waterproofing, electric leakage protection, and breaker
Turn-back type air inflow & outlet design reduces noise and improves engine efficiency
Practical design with bottom holes for forklift, water outlet, and oil outlet for easy maintenance
Double open doors on both sides for comprehensive engine and alternator access
Available in silent, super silent, soundproof, trailer type, and container type configurations
Compliance with major standards: GB/T2820, ISO8528, IEC34, CE, EPA Tier4

Technical Specifications

General Information	Prime Power	Standby Power
Rated Power (kVA)	250	275
Power Rating (kW)	200	220
Frequency (Hz)	50
Engine Model	6DTAA8.9-G23
Engine Speed (RPM)	1500
Phase	3
PF	0.8
Control System	Digital
Rated Voltage (V)	400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time	≥ 8h @ 75% load

Power Rating Definitions

PRP (Prime Power): Available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour operation.

ESP (Emergency Standby Power): Applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.

Dimensions and Weight

Model	BSD275 (Open Type)	BSD275S (Silent Type)
Length (L) mm	2600	3550
Width (W) mm	1000	1220
Height (H) mm	1850	1950
Tank Capacity (L)	460	460

Engine Specifications

Engine Model & Manufacturer	6DTAA8.9-G23 (SDEC)
Engine Type	In-line, 4 strokes, water-cooled; 4 valves, Turbo charged with aftercooler
Combustion Type	Direct injection
Cylinder Type	Wet cylinder liner
Number of Cylinders	6
Bore × Stroke	114 × 144 mm
Displacement	8.82 lit.
Compression Ratio	16.5 : 1
Firing Order	1-5-3-6-2-4
Fuel Injection Advance Angle	8.5°BTDC
Dry Weight	900 kg
Dimension	1493×792×1309mm
Rotation	CCW viewed from flywheel
Fly Wheel Housing	SAE 2#
Fly Wheel	SAE 11.5# (number of teeth: 125)

Alternator Specifications

Alternator Brand	BOBIG
Alternator Manufacturer	FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model	BW-274K
Alternator Rated Power	200kw/250kva
Rated Voltage (V)	230v/400v
Rated Frequency	50hz
Connecting Type	3 Phase and 4 W
Number of Bearing	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class	H class
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%～+20%

Product Images

Front View

Side View

Control Panel

Engine Detail

Alternator View

Silent Type Exterior

Internal Components

Cooling System

Fuel System

Electrical Connections

Full Assembly

Quality Inspection

Specifications and illustrations are subject to revision without notice.
