220v 230v 380v Super Diesel Silent Generator 480kW 600KVA 50/60HZ Electric Starter Single/Three Phase Portable Generators

220v 230v 380v Super Diesel Silent Generator 480kW 600KVA 50/60HZ Electric Starter Single/Three Phase Portable Generators
Features Gallery Product Description Request A Quote
Features
Specifications
Canopy: Customized
Warranty: 12 Months/1000 Hours
Type: Silent(super Silent)or Open, Silent, Etc, In-line/6-Cylinder/4-Stroke/4-Valve/19L, Soundproof Canopy(Silent)
Control Panel: LCD Digital Display, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen
Output Type: AC Single/Three Phase
Controller: Deepsea/Smartgen/etc
Application: Indursty Bank Etc
Rated Voltage: 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V
Alternator: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford Or Newtec, Engga
Product Name: Diesel Genertor, Generator 600KVA , Powered By CUMMIN S Diesel Generator, Standby Use Power Diesel Generator 480kW
Color: Customers' Requirement
Frequency: 50/60HZ
Rated Power: 480kW
Engine: Original CUMMIN S
Cooling Method: Water-cooling System
Highlight:

220v diesel silent generator 600KVA

,

380v portable generator electric starter

,

Cummins diesel generator three phase
Basic Infomation
Place of Origin: China
Brand Name: CUMMIN S
Certification: CE
Model Number: KTAA19-G6
Payment & Shipping Terms
Packaging Details: Bubble wrap
Delivery Time: 30 days
Supply Ability: 500pcs per month
Product Description
480kW 600KVA BOBIG CUMMIN S Diesel Generator
Model: KTAA19-G6 - Reliable Power Solution
Our 480kW 600KVA BOBIG CUMMIN S diesel generator (Model: KTAA19-G6) is designed to provide reliable power for a wide range of applications. Backed by the renowned CUMMIN S brand, it offers high-quality performance and long-term durability.
Key Features
Power Performance
Rated Power: 480kW (600KVA) to meet various industrial, commercial, and residential power needs. The prime power output is stable and efficient, ensuring continuous operation under heavy loads.
Frequency: Standard 50Hz operation suitable for most electrical equipment.
Engine Excellence
Engine Model: KTAA19-G6 CUMMIN S engine combining advanced technology with high-quality manufacturing for high torque, fuel efficiency, and low emissions.
Engine Speed: 1500 RPM for smooth, consistent power supply with minimal component wear.
Technical Specifications
General Information Prime Power Standby Power
Rated Power (kVA) 600 660
Power Rating (kW) 480 528
Frequency (Hz) 50
Engine Model KTAA19-G6
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (Customizable)
Fuel Tank Capacity Operating Time ≥ 8h @ 75% load
PRP Prime Power: Available for unlimited annual hours in variable load applications according to GB/T2820-97. 10% overload capability available for 1 hour within 12-hour operation.
ESP Standby Power: Applicable for emergency power supply during utility interruptions. No overload, utility parallel, or negotiated outage operation capability.
Dimensions and Weight
Model BC660 (Open Type) BC660S (Silent Type)
Length (mm) 3600 4600
Width (mm) 1500 2000
Height (mm) 2460 2360
Tank Capacity (L) 1104 1104
Engine Specifications
Engine Model & Manufacturer KTAA19-G6 (Cummin s)
Number of Cylinders 6
Cylinder Arrangement In-line
Cycle Four Stroke
Aspiration Turbocharged & Air-Air Intercooler
Bore x Stroke 159 x 159 mm
Displacement 19 L
Compression Ratio 13.9:1
Prime Power/Speed 520 kW/1500 rpm
Standby Power/Speed 578 kW/1500 rpm
Fuel System Cummin s PT
Cooling System Force Water Cooling Cycle
Frequency Droop ≤ 3%
Total Lubrication System Capacity 19.1 L
Coolant Capacity (Engine Only) 10.2 L
Fuel Consumption @ 100% Load 215 g/kWh @1500 rpm
Starter Motor DC 24V
Charge Alternator DC 24V
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-3354ES
Alternator Rated Power 480kW/600kVA
Rated Voltage 230V/400V
Rated Frequency 50Hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%~+20%
Environmental Adaptability
Ambient Temperature
Operates effectively in temperatures from +5°C to +40°C
Altitude
Suitable for use at altitudes up to 1000m
Customized solutions available for different environmental conditions.
Applications
  • Industrial Use: Backup power for factories to ensure continuous production during outages
  • Commercial Buildings: Power for office buildings, shopping malls, and hotels to maintain essential services
  • Residential Areas: Reliable power for communities with unstable power grids
Customization & Services
We support customization and OEM services with design drawings.
All units are equipped with original power supplies and standard DSE 6120 controller. Engine, generator, and controller options are available.
Packaging & Shipping
Plywood case packaging. Delivery within 10-15 working days after receiving customer deposit.
Warranty
BOBIG products have a one-year or 1000-hour warranty (whichever comes first) from ex-factory date. Includes free replacement of easy-damageable spare parts due to production or material quality issues.
Certifications
Complies with international standards: ISO 8528-5:2018, GB/T2820.5-2009, and CE certification.
BOBIG Generator Certification 1 BOBIG Generator Certification 2
Product Image
480kW 600KVA BOBIG CUMMIN S Diesel Generator
Why Choose BOBIG
  • Brand Reputation: CUMMIN S is a trusted brand with long history of quality products
  • Quality Assurance: Manufactured to international standards with rigorous quality inspections
  • Customization Options: Tailored solutions based on specific requirements
  • Professional Support: 24/7 technical support, maintenance, and repair services
