Durable High Quality 45kva Intelligent diesel Generator 36kw 45kva Open Type Silent diesel Electric Power Make Generator 36kw

Durable High Quality 45kva Intelligent diesel Generator 36kw 45kva Open Type Silent diesel Electric Power Make Generator 36kw
Features Gallery Product Description Request A Quote
Features
Specifications
Canopy: Customized
Warranty: 12 Months/1000 Hours
Type: Silent(super Silent)or Open, Silent, Etc, In-line/6-Cylinder/4-Stroke/4-Valve/19L, Soundproof Canopy(Silent)
Control Panel: LCD Digital Display, Deepsea, ComAp, Deepsea / ComAp / Harsen / Smartgen 6110, Smartgen
Output Type: AC Single/Three Phase
Controller: Deepsea/Smartgen/etc
Application: Indursty Bank Etc
Rated Voltage: 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V
Alternator: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford Or Newtec, Engga
Product Name: Diesel Genertor, Generator 36kw , Powered By YUCHAI Diesel Generator, Standby Use Power Diesel Generator 36kw
Color: Customers' Requirement
Frequency: 50/60HZ
Rated Power: 45kva
Engine: Original YANGDONG
Cooling Method: Water-cooling System
Highlight:

45kva diesel generator with warranty

,

36kw silent diesel generator

,

open type electric power generator

Basic Infomation
Place of Origin: China
Brand Name: YANGDONG
Certification: CE
Model Number: Y4110D
Payment & Shipping Terms
Packaging Details: Plywood
Delivery Time: 30 days
Supply Ability: 500pcs per month
Product Description
36kW 45KVA BOBIG YANGDONG Diesel Generator (Model: Y4110D)
Our 36kW 45KVA BOBIG YANGDONG diesel generator (Model: Y4110D) is designed to provide reliable power for a wide range of applications. Backed by the YANGDONG brand, it offers high-quality performance and long-term durability.
Key Features
Power Performance
  • Rated Power: 36kW (45KVA) for various industrial, commercial, and residential applications
  • Frequency: 50Hz standard frequency suitable for most electrical equipment
Engine Excellence
  • Engine Model: Y4110D YANGDONG engine with high torque, fuel efficiency, and low emissions
  • Engine Speed: 1500 RPM for smooth and consistent power supply
Technical Specifications
General Information
Specification Prime Power Standby Power
Rated Power (kVA) 45 50
Power Rating (kW) 36 40
Frequency (Hz) 50
Engine Model Y4110D
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (customizable)
Fuel Tank Capacity Operating Time ≥ 8h @ 75% load
Engine Details
Parameter Specification
Engine Model & Manufacturer Y4110D (YANGDONG)
No. of Cylinders 4
Injection Type Direct
Aspiration Natural
Configuration Vertical
Bore 110 mm
Stroke 118 mm
Compression Ratio 18
Displacement 4.484 L
Dry Engine Weight 330 kg
Dimension (L*W*H) 892*618*740 mm
The Flywheel Shell Interface SAE3
Governed Engine Speed 1500
Continuous Power without Fans 43
Standby Power 48
Number of Flywheel Teeth 119
Alternator Specifications
Parameter Specification
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-224C
Alternator Rated Power 36kw/45kva
Rated Voltage (V) 230v/400v
Rated Frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%~+20%
Dimensions and Weight
Model BY50 (Open Type) BY50S (Silent Type)
Length (L) mm 1650 2250
Width (W) mm 610 880
Height (H) mm 1170 1100
Tank Capacity (L) 83 83
Applications
  • Industrial Use: Backup power source for factories to ensure continuous production during power outages
  • Commercial Buildings: Power for office buildings, shopping malls, and hotels to maintain essential services
  • Residential Areas: Reliable power for communities with unstable power grids
Warranty and Service
BOBIG products have a guarantee for one year or 1000 hours (whichever comes first) from the ex-factory date. During the guarantee period, we provide free replacement of easy-damageable spare parts caused by production or material quality issues. After expiration, we provide cost-based spare parts maintenance with 24/7 technical support.
Why Choose Us
  • Brand Reputation: YANGDONG is a trusted brand with a long history of producing high-quality products
  • Quality Assurance: Manufactured in strict accordance with international standards with rigorous quality inspections
  • Customization Options: Tailored solutions based on your specific requirements
Frequently Asked Questions
What is your MOQ, payment method, delivery time?
Our MOQ is only 1 set. Payment method is usually 30% T/T as deposit, 70% balance T/T before delivery. Delivery period is normally 10-15 working days after receiving customer deposit.
Which port do you often use when export?
Fuzhou port, Fujian province or as customer request.
Is there any spare parts you can provide along with generators?
We provide regular engine's air filter, water filter, fuel filter, and oil filter for customer self-maintenance.
Can you offer parts to us if we need?
Yes, we can offer parts at any time, not limited to warranty period. Parts are usually shipped within 3-5 days.
Can you customize voltage, frequency, tank capacity, phase and color?
Yes, all specifications can be customized according to your needs.
What is your distribution policy?
We welcome distributors worldwide. We can issue authority certificates and sign agreements accordingly.
