Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V

1
MOQ
Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Voltage: 400/230V,220V / 380V
Speed: 1500/1800rpm
Frequency: 50/60HZ
Rated Current: Depend
Rated Power: 6kva-3000kva
Output Type: AC Single/Three Phase
Warranty: 12 Months/1000 Hours
Alternator: Stamford
Type: Silent(super Silent)or Open
Product Name: Diesel Genertor
Engine: Powered By Cummins
Controller: Deepsea/Smartgen/etc
Options: Customer's Logo,ATS,ABB/ATS/Container/Trailer,tank Capacity,Soundproof Canopy
Color: Customers' Requirement
Protection Class: IP21-23
Cooling Method: Water-cooling System
Application: Sea Shipping
High Light:

Sturdy Housing 125kva Cummins Generator

,

Sturdy Housing Cummins Silent Dg Set

,

Cummins Silent Dg Set 220V

Basic Infomation
Place of Origin: China
Brand Name: cummins
Certification: ISO CE
Model Number: BC series
Payment & Shipping Terms
Packaging Details: Bubble Wrap or Plywood Case
Delivery Time: 30 working days
Product Description

High quality 100kw 125kva  diesel generator prices with cummins engine

Products Features:
1.We cooperate with famous diesel engine -Powered by Cummins, Perkins Deutz , LovoL , Lister Petter, Doosan, Shangchai, Yarman, Foton-Isuzu, FAW, SDEC, Weichai, MTU, Ricardo, Jichai,ETC
2. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working
3. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen , ComAp ,
4. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
5. High protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker,High water temperature protection,Engine oil alarm, Over load protection, Overfrequency protection, Emergency stop unit
6. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
7. All new design for diesel generator set of Silent, Supper silent, Soundproof, Trailer type, Container type.





l Gensets power(KW/KVA) Engine
model
Engine power/kw BOBIG Open type (MM) sounproof type (MM)
Prime Standby Prime
BC24.75S 18 23 20 25 4B3.9-G11 30 BW-184ES 1600*720*1300 2100*930*1200
BC33S 24 30 26 33 4B3.9-G2 30 BW-184F 1600*720*1300 2100*930*1200
BC41.25S 30 38 33 41 4B3.9-G12 33 BW-184G 1600*720*1300 2250*930*1220
BC49.5S 36 45 40 50 4BT3.9-G2 40 BW-184H 1600*720*1300 2250*930*1220
BC68.75S 50 63 55 69 4BTA3.9-G2 60 BW-224D 1750*770*1370 2450*970*1250
BC77S 56 70 62 77 4BTA3.9-G11 80 BW-224E 1880*770*1400 2500*970*1250
BC93.5S 68 85 75 94 4BTA3.9-G11 80 BW-224F 1880*770*1400 2500*970*1250
BC110S 80 100 88 110 4BTA3.9-G13 97 BW-224G 2120*850*1400 2850*1040*1430
BC123.75S 90 113 99 124 4BTA3.9-G13 97 BW-274C 2120*850*1400 2850*1040*1430
BC137.5S 100 125 110 138 4BTAA3.9-G3 106 BW-274D 2120*850*1400 2850*1040*1430
BC123.75S 90 113 99 124 6BT5.9-G2 100 BW-274C 2120*850*1400 2850*1040*1430
BC137.5S 100 125 110 138 6BT5.9-G2(115) 115 BW-274D 2120*850*1400 2850*1040*1430
BC151.25S 110 138 121 151 6BTA5.9-G2 120 BW-274D 2120*850*1400 2950*1040*1430
BC165S 120 150 132 165 6BTAA5.9-G2 132 BW-274E 2350*850*1450 3000*1120*1440
BC178.75S 130 163 143 179 6BTAA5.9-G12 150 BW-274E 2500*900*1600 3150*1120*1530
BC206.25S 150 188 165 206 6CTA8.3-G2 170 BW-274F 2570*950*1850 3150*1120*1560
BC233.75S 170 213 187 234 6CTAA8.3-G2 190 BW-274G 2570*950*1850 3400*1220*1780
BC275S 200 250 220 275 6LTAA8.9-G2 235 BW-274J 2850*1110*2100 3400*1220*1780
BC302.5S 220 275 242 303 6LTAA8.9-G3 255 BW-274K 2850*1110*2100 3400*1220*1780
BC330S 240 300 264 330 6LTAA9.5-G3 255 BK314CS 2850*1110*2100 3950*1400*1950
BC343.75S 250 313 275 344 6LTAA9.5-G1 265 BW-314D 2850*1110*2100 3950*1400*1950
BC412.5S 300 375 330 413 6ZTAA13-G3 340 BW-314E 3150*1400*2180 4200*1600*2250
BC484S 352 440 387 484 6ZTAA13-G2 390 BW-314F 3150*1400*2180 4200*1600*2250
BC495S 360 450 396 495 6ZTAA13-G4 400 BW-314F 3150*1400*2180 4200*1600*2250
BC550S 400 500 440 550 QSZ13-G3 450 BW-354C 3350*1300*2460 4200*1600*2430
BC618.75S 450 563 495 619 QSZ13-G11 512 BW-354C 3350*1300*2460 4200*1600*2430
BC343.75S 250 313 275 344 NTA855-G1 287 BW-314D 3100*1050*2100 4200*1400*2120
BC378.125S 275 344 303 378 NTA855-G1B 313 BW-314D 3100*1050*2100 4200*1400*2120
BC440S 320 400 352 440 NTA855-G3 358 BW-314E 3100*1050*2100 4200*1500*2100
BC481.25S 350 438 385 481 KTA19-G2 392 BW-314F 3350*1300*2460 4600*1580*2200
BC563.75S 410 513 451 564 KTA19-G3 463 BW-354C 3350*1300*2460 4600*1580*2200
BC618.75S 450 563 495 619 KTA19-G3A 507 BW-354C 3350*1300*2460 4600*1580*2200
BC687.5S 500 625 550 688 KTAA19-G5 533 BW-354ES 3650*1500*2460 4600*2000*2360
BC756.25S 550 688 605 756 QSK19-G5 608 BW-354E 3600*1900*2250 5000*2000*2400
BC852.5S 620 775 682 853 KT38-G 679 BW-354F 4300*1750*3125 5600*2200*2550
BC962.5S 700 875 770 963 KTA38-G1 769 BW-404C 4300*1750*3125 5600*2200*2550
BC1031.25S 750 938 825 1031 KTA38-G2 809 BW-404D 4300*1750*3125 5600*2200*2550
BC1031.25S 750 938 825 1031 KTA38-G2B 830 BW-404D 4300*1750*3125 5600*2200*2550
BC1100S 800 1000 880 1100 KTA38-G2A 915 BW-404D 4300*1750*3125 5600*2200*2550
BC1237.5S 900 1125 990 1238 KTA38-G4 1004 BW-404E 4300*1750*3125 6100*2250*3050
BC1320S 960 1200 1056 1320 QSK38-G5 1063 BW-404F 5200*2150*2550 6100*2250*3050
BC1512.5S 1100 1375 1210 1513 KTA38-G9 1220 BW-404G 4950*2000*2500 6100*2250*3050
BC1512.5S 1100 1375 1210 1513 KTA50-G3 1220 BW-404G 5200*2150*2550 6100*2250*3050
BC1650S 1200 1500 1320 1650 KTA50-G9 1380 BW-454B 5600*2150*2550 6100*2250*3050

Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 0

Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 1

Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 2



Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 3Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 4

Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 5Sturdy Housing 100kw 125kva Cummins Generator Cummins Silent Dg Set 220V 380V 6

Safety - Stability - Economy - Reliability Power
Our generator set compliance with all main standards, such as : GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard


Controller System
Standard AMF control panel, including digital LED genset control model: HGM6120U, DSE7320, DSE6020, AMF20, AMF25


Manufacturing Standard
GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard ,GB755,BS 5000,VDE 0530, NEMA MG1-22,IEC34.
